Model No |
GSL-CESS-100K |
GSL-CESS-215K |
|
Battery Energy Storage |
||
|
Model
|
50TS(DC100)(100kwh) |
100TS(DC100)(215kwh) |
|
Max. PV input power
|
50kW |
100kW |
|
Max. PV input voltage |
620V |
680V |
|
STS
|
STS optional
|
|
|
Transformer
|
Transformer inside |
|
|
Battery DC |
||
|
Rated battery capacity |
100kWh |
215kWh |
|
Rated system voltage
|
691.2V |
768V |
|
Battery type
|
Lithium iron phosphate battery (LFP) |
|
|
Battery Cell capacity
|
120Ah |
280Ah |
|
Series of battery
|
1P*24S*11S |
1P*20S*12S |
|
AC |
||
|
Rated AC power
|
100KW |
100KW |
|
Rated AC current
|
72A |
144A |
|
Rated AC voltage
|
400V,3P+N+PE,50/60Hz |
|
|
THDi |
<3%(rated power) |
|
|
PF
|
-1 leading to+1 lagging |
|
|
General Parameters |
||
|
Protection level |
IP55 |
|
|
Isolation mode |
Non-lsolation (Adding isolation transformer is optional) |
|
|
Operating temperature |
-25~60℃(Derating above 45℃) |
|
|
Altitude |
3000m(>3000m derating) |
|
|
Communication interface |
RS485/CAN 2.0/ Ethernet/dry contact |
|
|
Dimension(W*D *H) |
1800*1200*2300mm |
1800*1200*2300mm |
|
Weight (with battery) |
3000kg |
3000kg |
